| P
|
螺距 |
| dp
|
最小值 |
| 最大值 |
| e
|
最小值 |
| k
|
公称 |
| 最小值 |
| 最大值 |
| r
|
最小值 |
| z
|
最小值 |
| 最大值 |
| s
|
最小值 |
| 最大值 |
|
| 0.8 |
1 |
1.25 |
1.5 |
1.75 |
2 |
2.5 |
| 3.2 |
3.7 |
5.2 |
6.64 |
8.14 |
11.57 |
14.57 |
| 3.5 |
4 |
5.5 |
7.0 |
8.5 |
12 |
15 |
| 6 |
7.3 |
9.7 |
12.2 |
14.7 |
20.9 |
27.1 |
| 5 |
6 |
7 |
8 |
10 |
14 |
18 |
| 4.85 |
5.85 |
6.82 |
7.82 |
9.82 |
13.785 |
17.785 |
| 5.15 |
6.15 |
7.18 |
8.18 |
10.18 |
14.215 |
18.215 |
| 0.2 |
0.25 |
0.4 |
0.4 |
0.6 |
0.6 |
0.8 |
| 3.5 |
4 |
5 |
6 |
7 |
9 |
11 |
| 3.8 |
4.3 |
5.3 |
6.3 |
7.36 |
9.36 |
11.43 |
| 4.82 |
5.82 |
7.78 |
9.78 |
11.73 |
16.73 |
21.67 |
| 5 |
6 |
8 |
10 |
12 |
17 |
22 |
|
